P

Paint Coulomb Efficiency


Function Name:	`PaintCoulombEfficiency`
Dimensions:	[Mass/Electric Charge]
Default units:	kg/s-A
Type:	Scalar
Activated by:	Electro-Deposition Coating

Paint Density

See Eqn. (4182).


Function Name:	`PaintDensity`
Dimensions:	[Mass/Volume]
Default units:	kg/m^3
Type:	Scalar
Activated by:	Electro-Deposition Coating

Paint Electrical Resistance Area

See Eqn. (4179).


Function Name:	`PaintElectricalResistanceArea`
Dimensions:	[Electric Potential-Length^2/Current]
Default units:	V-m^2/A
Type:	Scalar
Activated by:	Electro-Deposition Coating

Paint Electrical Resistivity

See Eqn. (4179).


Function Name:	`PaintElectricalResistivity`
Dimensions:	[Electric Potential-Length/Current]
Default units:	V-m/A
Type:	Scalar
Activated by:	Electro-Deposition Coating

Paint Layer Thickness

See Eqn. (4182).


Function Name:	`PaintLayerThickness`
Dimensions:	[Length]
Default units:	m
Type:	Scalar
Activated by:	Electro-Deposition Coating

Paint Layer Thickness Growth Rate

See Eqn. (4182).


Function Name:	`PaintLayerThicknessGrowthRate`
Dimensions:	[Length/Time]
Default units:	m/s
Type:	Scalar
Activated by:	Electro-Deposition Coating

Parcel Axis Orientation i | j | k

The Parcel Axes Orientation are the vectors which represent how the three axes of the system local to the particle are transformed after the corresponding rotation is applied.


Function Name:	`ParcelAxisOrientationI \| J \| K`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Vector
Activated by:	DEM Particles

Parcel Cell Index

Unique index assigned to each parcel within a cell. The index is only unique within the cell.


Function Name:	`ParcelCellIndex`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	DEM Particles

Parcel Centroid

The position of parcels,

r_{π}


Function Name:	`ParcelCentroid`
Dimensions:	[Length]
Default units:	m
Type:	Position
Activated by:	DEM Particles, Massless Particles model, Material Particles model

Parcel DEM Timestep

See Eqn. (3244) through Eqn. (3247).


Function Name:	`ParcelDEMTimestep`
Dimensions:	[Time]
Default units:	s
Type:	Scalar
Activated by:	DEM Particles

Parcel Displacement

The displacement vector of the parcel.


Function Name:	`ParcelDisplacement`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Vector
Activated by:	DEM Particles

Parcel Halo Count

Used in debugging.


Function Name:	`ParcelHaloCount`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	DEM Particles

Parcel Halo Marker

Used in debugging.


Function Name:	`ParcelHaloMarker`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	DEM Particles

Parcel Index

A unique identifier for each parcel. The index is unique within a Lagrangian phase.


Function Name:	`ParcelId`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Blob Detection, Lagrangian Multiphase model

Parcel Intersection Face Normal

The outward pointing normal of the cell face that the parcel currently intersects. If the normal is a zero vector, it means that the parcel is inside a cell, not at any face. This function can be used to define properties such as coefficients of restitution or composite mode probabilities.


Function Name:	`IntersectionFaceNormal`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Vector
Activated by:	Lagrangian Multiphase model

Parcel Kinetic Energy

The kinetic energy of the parcel.


Function Name:	`ParcelKineticEnergy`
Dimensions:	[Energy]
Default units:	J
Type:	Scalar
Activated by:	DEM Particles

Parcel Local Index

Unique index assigned to each parcel in a region. The index is only unique within the region.


Function Name:	`ParcelLocalIndex`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	DEM Particles

Parcel Mass

The mass of parcels,

m_{π} = {n_{π} m}_{p}

. (Unsteady)


Function Name:	`ParcelMass`
Dimensions:	[Mass]
Default units:	kg
Type:	Scalar
Activated by:	Material Particles model, DEM Particles

Parcel Mass Flow Rate

The mass of parcels,

{\dot{m}}_{π} = {{\dot{n}}_{π} m}_{p}

. (Steady)


Function Name:	`ParcelMassFlowRate`
Dimensions:	[Mass/Time]
Default units:	kg/s
Type:	Scalar
Activated by:	Material Particles model

Parcel Orientation

The orientation vector of the parcel, expressed as Euler angles.


Function Name:	`ParcelOrientation`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Vector
Activated by:	DEM Particles

Parcel Region Index

Unique index assigned to each region containing parcels.


Function Name:	`ParcelRegionIndex`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	DEM Particles

Parcel Retrack Mask


Function Name:	`ParcelRetrackMask`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	DEM Particles

Parcel Rotation Kinetic Energy

The rotational kinetic energy of the parcel.


Function Name:	`ParcelRotationKineticEnergy`
Dimensions:	[Energy]
Default units:	J
Type:	Scalar
Activated by:	DEM Particles

Parcel Size

Radius

R_{π}

of an equivalent sphere of mass and density equal to that of the parcel

R_{π} = 0.5 D_{p} \sqrt[3]{n_{π}}

, where

n_{π}

is the Particle Count. This field function sets the display size of parcels in scenes when the Point Scale Mode of a scalar displayer is set to Particle Model. This function is also the default function for the Point Size Scale Field when Point Scale Mode is set to Scalar. In steady simulations, Parcel Size evaluates to zero. Do not use Parcel Size for scaling parcel displays in steady simulations.


Function Name:	`ParcelSize`
Dimensions:	[Length]
Default units:	m
Type:	Scalar
Activated by:	DEM Particles, Material Particles model

Parcel Time Step

The local time-step,

δ t_{p}

in Eqn. (3326) and Eqn. (3327).


Function Name:	`ParcelTimeStep`
Dimensions:	[Time]
Default units:	s
Type:	Scalar
Activated by:	Massless Particles model, Lagrangian Multiphase model

Parcel Volume

The volume of parcels,

V_{π} = n_{π} V_{p}

. (read-only). (Unsteady)


Function Name:	`ParcelVolume`
Dimensions:	[Volume]
Default units:	m^3
Type:	Scalar
Activated by:	DEM Particles, Lagrangian Multiphase model

Parcel Volume Flow Rate

The volume of parcels,

{\dot{V}}_{π} = {\dot{n}}_{π} V_{p}

. (Steady)


Function Name:	`ParcelVolumeFlowRate`
Dimensions:	[Volume/Time]
Default units:	m^3/s
Type:	Scalar
Activated by:	Material Particles model

Particle Angular Momentum

I_{p} ω_{p}

. See Eqn. (2960).


Function Name:	`ParticleAngularMomentum`
Dimensions:	[Mass-Length^2/Time]
Default units:	kg-m^2/s
Type:	Vector
Activated by:	DEM Particles

Particle Angular Velocity

ω_{p}

in Eqn. (2960).


Function Name:	`ParticleAngularVelocity`
Dimensions:	[Angular Velocity]
Default units:	rad/s
Type:	Vector
Activated by:	DEM Particles

Particle Bonded Components

The labels (integers) of bonded particle clusters. These clusters are groups of particles that form a single connected network through particle-particle bonds. Compare with the Particle Connected Components field function.


Function Name:	`ParticleBondedComponents`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Flexible Fiber, Particle Agglomeration, Particle Clumps

Particle Bonded Component Size

The number of spheres or segments in the bonded particle cluster to which a given particle belongs. Compare with the Particle Connected Component Size field function.


Function Name:	`ParticleBondedComponentSize`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Flexible Fiber, Particle Agglomeration, Particle Clumps

Particle Charge

The particle charge

q


Function Name:	`ParticleCharge`
Dimensions:	[Electric Charge]
Default units:	Coulomb
Type:	Scalar
Activated by:	Coulomb Force

Particle Clift Drag Coefficient

The Clift drag coefficient

C_{d}

for the particle. See Eqn. (2969).


Function Name:	`ParticleCliftDragCoefficient`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	DEM Particles, Lagrangian Multiphase model

Particle Component Index

This field function displays the index numbers associated with the components of the particles (spheres for Particles Clumps or segments for Flexible Fiber). Each particle component has a unique index that distinguishes it.


Function Name:	`ParticleComponentIndex`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Flexible Fiber, Particle Clumps

Particle Connected Components

The labels (integers) of particle clusters. These clusters are groups of particles that form a single connected network through particle-particle contact. Compare with the Bonded Components field function.


Function Name:	`ParticleConnectedComponents`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	DEM Particles

Particle Connected Component Size

The number of spheres in the particle cluster to which the given particle belongs. Compare with the Bonded Component Size field function.


Function Name:	`ParticleConnectedComponentSize`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	DEM Particles

Particle Count

The number of particles that are represented by a parcel,

n_{π}

. (Unsteady)


Function Name:	`ParticleCount`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	DEM Particles, Lagrangian Multiphase model

Particle Critical Velocity

The critical velocity of the particle

v_{crit}

in Eqn. (3263) resulting from the force as estimated by the Hertz-Mindlin contact model. Once the particle exceeds this velocity, it has enough energy to exit the domain through a planar wall.


Function Name:	`ParticleCriticalVelocity`
Dimensions:	[Velocity]
Default units:	m/s
Type:	Scalar
Activated by:	DEM Particles

Particle Density

The density of the particle material,

ρ_{p}


Function Name:	`ParticleDensity`
Dimensions:	[Mass/Volume]
Default units:	kg/m^3
Type:	Scalar
Activated by:	DEM Particles, Material Particles model

Particle DiFelice Drag Coefficient

The DiFelice drag coefficient

C_{d}

for the particle. See Eqn. (2971).


Function Name:	`ParticleDiFeliceDragCoefficient`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	DEM Particles, Lagrangian Multiphase model

Particle Diameter

The diameter of particles,

D_{p}


Function Name:	`ParticleDiameter`
Dimensions:	[Length]
Default units:	m
Type:	Scalar
Activated by:	Material Particles model

Particle Drag Force

The drag force on a particle,

F_{d}


Function Name:	`ParticleDragForce`
Dimensions:	[Force]
Default units:	N
Type:	Vector
Activated by:	Drag Force model

Particle EMMS Drag Coefficient

The EMMS drag coefficient

C_{d}

for the particle in Eqn. (2975).


Function Name:	`ParticleEMMSDragCoefficient`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	DEM Particles, Lagrangian Multiphase model

Particle Enthalpy

The energy per unit mass of a particle.


Function Name:	`ParticleEnthalpy`
Dimensions:	[Energy/Mass]
Default units:	J/kg
Type:	Scalar
Activated by:	Lagrangian Energy Model, Two-Way Coupling model

Particle Ergun Drag Coefficient

The Ergun drag coefficient

C_{d}

for the particle. See Eqn. (2974).


Function Name:	`ParticleErgunDragCoefficient`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	DEM Particles, Lagrangian Multiphase

Particle Flow Rate

The rate at which particles flow along parcel tracks,

{\dot{n}}_{π}

. (Steady)


Function Name:	`ParticleFlowRate`
Dimensions:	[/Time]
Default units:	/s
Type:	Scalar
Activated by:	Lagrangian Multiphase model

Particle Gidaspow Default Drag Coefficient

The Gidaspow drag coefficient is equal to the Wen-Yu coefficient Eqn. (2973) or the Ergun coefficient Eqn. (2974), depending on the value of the void fraction

ϵ


Function Name:	`ParticleGidaspowDefaultDragCoefficient`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	DEM Particles, Lagrangian Multiphase model

Particle Haider Levenspiel Drag Coefficient

The Haider Levenspiel drag coefficient

C_{d}

for the particle. See Eqn. (2976).


Function Name:	`ParticleHaiderLevenspielDragCoefficient`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	DEM Particles, Lagrangian Multiphase model

Particle Impact Velocity Magnitude

The magnitude of the relative velocity between the particle and the wall at the contact point.


Function Name:	`ParticleImpactVelocityMagnitude`
Dimensions:	[Velocity]
Default units:	m/s
Type:	Scalar
Activated by:	Impact Cutting

Particle Incidence Angle

The angle between the particle velocity vector and the plane of face on which it is incident, if any,

θ = asin (v_{p} \cdot n / | v_{p} |)

. This function is provided for use in boundary condition expressions, it is not available for visualization, reporting, or recording on the track file.


Function Name:	`ParticleIncidenceAngle`
Dimensions:	[Angle]
Default units:	rad
Type:	Scalar
Activated by:	DEM Particles, Material Particles model

Particle Kinetic Energy

The kinetic energy of the particle.


Function Name:	`ParticleKineticEnergy`
Dimensions:	[Energy]
Default units:	J
Type:	Scalar
Activated by:	DEM Particles

Particle Liu Drag Coefficient

The Liu dynamic drag coefficient

C_{d}

for the particle. See Eqn. (2967).


Function Name:	`ParticleLiuDrag Coefficient`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Lagrangian Multiphase model

Particle Mass

The mass of single particles,

m_{p}

. Note, not the mass of parcels.


Function Name:	`ParticleMass`
Dimensions:	[Mass]
Default units:	kg
Type:	Scalar
Activated by:	DEM Particles, Material Particles

Particle Mass Fraction of <Species>

The mass fraction,

Y_{p i} = {m_{p i} / m}_{p}

, of species i in a single particle.


Function Name:	`ParticleMassFraction<Species>`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Lagrangian Multiphase model

Particle Molar Concentration of <Species>

The molar concentration,

C_{p i} = ρ_{p} Y_{p i} / W_{p i}

, of species i in a single particle, where

ρ_{p}

is the particle mixture density,

Y_{p i}

is the species mass fraction, and

W_{p i}

is the species molecular weight.


Function Name:	`ParticleMolarConcentration<Species>`
Dimensions:	[Quantity/Volume]
Default units:	kmol/m^3
Type:	Scalar
Activated by:	Lagrangian Multiphase model

Particle Mole Fraction of <Species>

The mole fraction,

X_{p i} = Y_{p i} W_{p} / W_{i}

, of species i in a single particle, where

Y_{p i}

is the species mass fraction,

W_{p}

is the molecular weight of the particle mixture, and

W_{p i}

is the molecular weight of the species.


Function Name:	`ParticleMoleFraction<Species>`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Lagrangian Multiphase model

Particle Moment of Inertia

I_{p}

in Eqn. (2960). This quantity can be used for validation.


Function Name:	`ParticleMomentOfInertia`
Dimensions:	[Mass-Length^2]
Default units:	kg-m^2
Type:	Vector
Activated by:	DEM Particles

Particle Nusselt Number

The non-dimensional heat transfer coefficient of particles,

{Nu}_{p}

, defined in Eqn. (3025).


Function Name:	`ParticleNusseltNumber`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Lagrangian Energy model

Particle Permittivity

The relative permittivity of the particle

ϵ_{r}


Function Name:	`ParticlePermittivity`
Dimensions:	[Electrical Capacitance/Length]
Default units:	Farad/m
Type:	Scalar
Activated by:	Field Charging model

Particle Porosity

The porosity of particles within the Lagrangian phase.


Function Name:	`ParticlePorosity`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Particle Porosity model

Particle Projected Area

The cross-sectional area of the particle orthogonal to the direction of the fluid velocity relative to the particle centroid. Each particle in a fiber is treated separately; overlaps of cross-sections are not addressed. All other composite particles are treated as a unit and the projected area is numerically estimated.


Function Name:	`ParticleProjectedArea`
Dimensions:	[Length^2]
Default units:	m^2
Type:	Scalar
Activated by:	Particle Porosity model

Particle Projected Length

The average length of the particle parallel to the direction of the fluid velocity relative to the particle centroid. Each particle in a fiber is treated separately. All other composite particles are treated as a unit and the projected length is numerically estimated.


Function Name:	`ParticleProjectedLength`
Dimensions:	[Length]
Default units:	m
Type:	Scalar
Activated by:	DEM Particles

Particle Radiative Energy Source

The volumetric (integrated over dispersed media in a given cell) source due to radiative absorption and emission by dispersed media, such as particles (absorption by particles minus emission from particles). A positive value indicates net absorption by the dispersed media. This quantity is equal to the negative of the divergence of the radiative heat flux from dispersed media.


Function Name:	`code_name`
Dimensions:	[dimensions]
Default units:	units
Type:	type
Activated by:	linked model list

Particle Residence Time

The “age” of particles as measured from time of injection.


Function Name:	`Particle Residence Time`
Dimensions:	[Time]
Default units:	s
Type:	Scalar
Activated by:	Lagrangian Multiphase model

Particle Reynolds Number

The quantity

{Re}_{p}

in Eqn. (2966).


Function Name:	`ParticleReynoldsNumber`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Material Particles model

Particle Rotation Kinetic Energy

Allows post-processing of the kinetic energy of the rotating particle.


Function Name:	`ParticleRotationKineticEnergy`
Dimensions:	[Energy]
Default units:	J
Type:	Scalar
Activated by:	DEM Particles

Particle Schiller-Naumann Drag Coefficient

The Schiller-Naumann drag coefficient for the particle. See

C_{d}

in Eqn. (2965).


Function Name:	`ParticleSchillerNaumannDragCoefficient`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Lagrangian Multiphase model

Particle Sherwood Number

The non-dimensional mass transfer conductance,

{S h}_{p}

, defined in Eqn. (3238). (Mass Transfer)


Function Name:	`ParticleSherwoodNumber`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Lagrangian Multiphase model

ParticleSizeVariance of <phase>

σ

in Eqn. (2182).


Function Name:	`PArticelSizeVariance<Phase>`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Discrete Quadrature S-Gamma

Particle Slip Velocity

The velocity deficit of particles relative to the continuous phase,

v_{s} = v - v_{p}


Function Name:	`ParticleSlipVelocity`
Dimensions:	[Velocity]
Default units:	m/s
Type:	Array
Activated by:	DEM Particles, Material Particles model

Particle Smooth Source Group

Unsigned integer ID for the cluster to which a cell belongs when the cell cluster method is active for two-way coupling.


Function Name:	`GlobalClusterId`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Two-Way Coupling model, Two-Way Coupling solver

Particle Smooth Source Weight

The volume fraction of a cell relative to the total volume of the cluster in which it belongs. The fluid source terms generated by particles are summed over the cluster, then distributed back to the cell using this factor. The result is that the source contribution per unit volume is uniform across each cluster.


Function Name:	`CellClusterWeight`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Two-Way Coupling model, Two-Way Coupling solver

Particle Specific Heat

The specific heat of particles.


Function Name:	`ParticleSpecificHeat`
Dimensions:	[Energy/Mass-Temperature]
Default units:	J/kg-K
Type:	Scalar
Activated by:	Lagrangian Energy model

Particle Surface Area

The surface area of single particles,

A_{s}

. Note, not the surface area of parcels.


Function Name:	`ParticleSurfaceArea`
Dimensions:	[Length^2]
Default units:	m^2
Type:	Scalar
Activated by:	DEM Particles, Material Particles model

Particle Temperature

The temperature of particles,

T_{p}


Function Name:	`ParticleTemperature`
Dimensions:	[Temperature]
Default units:	K
Type:	Scalar
Activated by:	Lagrangian Energy model

Particle Velocity

The absolute velocity of particles,

v_{p}


Function Name:	`ParticleVelocity`
Dimensions:	[Velocity]
Default units:	m/s
Type:	Vector
Activated by:	DEM Particles, Lagrangian Multiphase model

Particle Volume

The volume of single particles,

V_{p} = m_{p} / ρ_{p}

. Note, not the volume of parcels.


Function Name:	`ParticleVolume`
Dimensions:	[Volume]
Default units:	m^3
Type:	Scalar
Activated by:	DEM Particles, Material Particles model

Particle Volume Overlap

How much of the particle is obscured by the contact area.


Function Name:	`ParticleVolumeOverlap`
Dimensions:	[Volume]
Default units:	m^3
Type:	Scalar
Activated by:	DEM Particles

Particle Wen-Yu Drag Coefficient

The Wen-Yu drag coefficient for the particle. See

C_{d}

in Eqn. (2973).


Function Name:	`ParticleWenYuDragCoefficient`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	DEM Particles, Lagrangian Multiphase model

Partition

The primary partition that the cell/face/vertex is on. When a simulation is run in parallel, the regions are decomposed across the number of processors such that each cell is allocated to a primary partition.


Function Name:	`Partitionid`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Volume mesh models

Part Surface Contract Index

Unique index assigned to each point of periodic contact on the part surface. Index only unique within the surface. (Read only.)


Function Name:	`PartSurfaceContractIndex`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:

<Passive Scalar>

The field function object that corresponds to a particular passive scalar material. This object makes the passive scalar available as a field function.


Function Name:	`Passive Scalar`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Passive Scalar

Periodic Index

Repeating interfaces can require multiple passes to intersect all faces. For example, a rotor-stator (sliding interface) case intersects once in situ, rotates/translates one side by the periodic transform and intersects again, and repeats until all faces are consumed. For a given intersected face, this value reports the number of steps that were required until it was matched. So it indicates how many multiples of the periodic transform must be applied to align it with the other side of the interface.


Function Name:	`PeriodicIndex`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Volume mesh models

Permeability

Represents the scalar magnetic permeability

μ

of isotropic materials (see Eqn. (4220) or Eqn. (4223)).


Function Name:	`Permeability`
Dimensions:	[Force/Current^2]
Default units:	H/m
Type:	Scalar
Activated by:	Finite Element Magnetic Vector Potential, Finite Volume Magnetic Vector Potential, Harmonic Balance FE Magnetic Vector Potential, Harmonic Balance FV Magnetic Vector Potential, Harmonic Balance FV Transverse Magnetic Potential, Transverse Magnetic Potential

Permeability (Symmetric Tensor)

Represents the magnetic permeability tensor

μ

of anisotropic solid materials (see Eqn. (4220) or Eqn. (4223)).


Function Name:	`Permeability (Symmetric Tensor)`
Dimensions:	[Force/Current^2]
Default units:	H/m
Type:	SymmetricTensor
Activated by:	Finite Element Magnetic Vector Potential

Permittivity

Corresponds to the material permittivity

ε

in Eqn. (4219).


Function Name:	`Permittivity`
Dimensions:	[Electrical Capacitance/Length]
Default units:	Farad/m
Type:	Scalar
Activated by:	Electrostatic Potential

Phase-Pair Reynolds Number (Primary Regime) of [Phase Interaction]

This value is

{R e}_{p s}

in Eqn. (2896).

Applies to Drag-Based Slip Velocity only.


Function Name:	`PhaseSlipVelocityPhase [phase interaction]`
Dimensions:	[Velocity]
Default units:	m/s
Type:	Array
Activated by:	Slip Velocity with Temporary Storage Retained activated in the Phase Slip Velocity solver

Phase-Pair Reynolds Number (Secondary Regime) of [Phase Interaction]

This value is

{R e}_{p s}

in Eqn. (2896).

Applies to Drag-Based Slip Velocity only.


Function Name:	`PhaseSlipVelocityPhase [phase interaction]`
Dimensions:	[Velocity]
Default units:	m/s
Type:	Array
Activated by:	Slip Velocity with Temporary Storage Retained activated in the Phase Slip Velocity solver

Phase Replacement Volume Fraction Limit of <phase interaction>

Positive values indicate shrinkage, negative values indicate expansion.


Function Name:	`PhaseReplacementVolumeFractionLimit<Phase Interaction>`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Macro Porosity

Phase Slip Velocity of [Phase Interaction]

This value is

v_{p s}

in Eqn. (2889).


Function Name:	`PhaseSlipVelocityPhase [phase interaction]`
Dimensions:	[Velocity]
Default units:	m/s
Type:	Array
Activated by:	Slip Velocity with Temporary Storage Retained activated in the Phase Slip Velocity solver

PiercedFaces

The number of faces of a surface pierced by one or more edges of another face.


Function Name:	`PiercedFaces`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:

Plastic Strain Energy Density

Represents the energy that is dissipated due to plastic deformation (see Eqn. (4517)).


Function Name:	`PlasticStrainEnergyDensity`
Dimensions:	[Energy/Volume]
Default units:	J/m^3
Type:	Scalar
Activated by:	Material Laws with Plasticity

Plastic Strain Tensor

ε_{p l}

in Eqn. (4515).


Function Name:	`PlasticStrainTensor`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Symmetric Tensor
Activated by:	Material Laws with Plasticity

Polymer Moment Dead <n>

Concentrations for dead moments Eqn. (3801), Eqn. (3803), and Eqn. (3805).


Function Name:	`DeadPolymerMoment<n>`
Dimensions:	[Quantity/Volume]
Default units:	kg/m³
Type:	Scalar
Activated by:	Polymerization model

Polymer Moment Live <n>

Concentrations of live moments Eqn. (3795), Eqn. (3797), and Eqn. (3799).


Function Name:	`LivePolymerMoment<n>`
Dimensions:	[Quantity/Volume]
Default units:	kg/m³
Type:	Scalar
Activated by:	Polymerization model

Polydispersity Index

See Eqn. (3807).


Function Name:	`Polydispersity Index`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Polymerization model

Polyhedron Elongation Factor

An ordered triple of multipliers defining stretch factors (>1) or shrink factors (<1) for the template polyhedron. See Polyhedron Elongation Factor.


Function Name:	`PolyhedronElongationFactor`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Array
Activated by:	Polyhedral Particles

Polymer Mass Average Chain Length

See Eqn. (3809).


Function Name:	`PolymerMassAvgChainLength`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Polymerization model

Polymer Number Average Chain Length

See Eqn. (3808).


Function Name:	`PolymerNumberAvgChainLength`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Polymerization model

Pore Volume Fraction of <Phase> @ <Critical Temperature>

The absolute pore volume fraction as given by Eqn. (374) for the critical temperature and the solidus temperature.


Function Name:	`PoreVolumeFraction<Phase>_<CriticalTemperature>`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Criteria Functions

Porous Solid Conductivity

The lumped conductivity of fluid plus solid in the porous region. The lumped conductivity is computed by weighting fluid and solid conductivities with porosity and (1 - porosity) respectively.


Function Name:	`PorousSolidConductivity`
Dimensions:	[Power/Length-Temperature]
Default units:	W/m-K
Type:	Scalar
Activated by:	Coupled Energy, Coupled Solid Energy, Segregated Fluid Enthalpy, Segregated Fluid Temperature, Segregated Solid Energy

Position

This field function displays the position of the vertices relative to the origin. It is available at vertices, faces, and cells. At faces and cells, the value represents the position of the respective face and cell centroids. This field function is the preferred option for specifying position dependencies of profiles and material properties when using field function methods. Position can be displayed as a Magnitude or as Laboratory coordinates. For a cell, the position is returned as the average of the positions of the vertices of the cell. This field function is the preferred option for specifying position dependencies of profiles and material properties when using field function methods. For more information, see Space Field Functions Reference.

Magnitude: Displays the absolute position.
Laboratory: Displays the position in either the X, Y, or Z direction.


Function Name:	`Position`
Dimensions:	[Length]
Default units:	m
Type:	Position
Activated by:	Space models

Power of Reaction

The energy release during the reaction time of the material.


Function Name:	`PowerOfReaction`
Dimensions:	[Power/Mass]
Default units:	W/kg
Type:	Scalar
Activated by:	Exothermic Solid

Pressure

The working pressure that is the solution variable in the flow models in Simcenter STAR-CCM+. It is the quantity

p

in Eqn. (947).


Function Name:	`Pressure`
Dimensions:	[Pressure]
Default units:	Pa
Type:	Scalar
Activated by:	Flow models, Harmonic Balance, Viscous Flow

Pressure Coefficient

The pressure coefficient is defined as:

C_{p} = (p - p_{ref}) / (\frac{1}{2} ρ_{ref} v_{ref}^{2})

where

p_{ref}

ρ_{ref}

, and

v_{ref}

are the Reference Pressure, Reference Density, and Reference Velocity that you specify in the field function, respectively.

This field function is not available in Eulerian multiphase models.


Function Name:	`PressureCoefficient`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Flow models

Pressure-Correction

The correction applied by the boundary condition to the pressure value specified at the boundary, in order to yield the specified mass flow rate.


Function Name:	`PPrime`
Dimensions:	[Pressure]
Default units:	Pa
Type:	Scalar
Activated by:	Melting-Solidification

Pressure Limiter


Function Name:	`PressureLimiter`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Melting-Solidification

Pressure Recon


Function Name:	`PressureRGrad`
Dimensions:	[Pressure/Length]
Default units:	Pa/m
Type:	Array
Activated by:	Melting-Solidification

PressureGrad

The pressure gradient

Δ P

times the cell volume. This becomes available when you activate the Coupled Solver and the Temporary Storage property.


Function Name:	`PressureGrad`
Dimensions:	[Pressure]
Default units:	Pa
Type:	Scalar
Activated by:	Coupled Flow with the Coupled Solver and the Temporary Storage property

Primary Atomization Status

A parcel has a value of 1 while primary atomization is in progress. When primary atomization is complete, or when primary atomization is bypassed because the Weber number is smaller than

{We}_{cr}

in Eqn. (3114), so that the parcel has moved onto secondary breakup, the value is 0.


Function Name:	`PrimaryAtomizationStatus`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Huh Atomization model

Primary Dendrite Arm Spacing of <Phase>

The Primary Dendrite Arm Spacing of the melting-solidifying phase.


Function Name:	`PrimaryDendriteArmSpacing<Phase>`
Dimensions:	[Length]
Default units:	m
Type:	Scalar
Activated by:	Criteria Functions

Prism Cell Thickness

Describes the thickness of each cell within the prism layers.

All the boundary faces, from which the prism layers grow, obtain the value of the prism layer total thickness.


Function Name:	`PrismCellThickness`
Dimensions:	[Length]
Default units:	m
Type:	Scalar
Activated by:	Space models

Prism Layer Cells

Allows you to view the cells present within a mesh generated by the prism layer mesher.


Function Name:	`PrismLayerCells`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Prism Layer Mesher

Prism Layer Number

Describes the layer number of cells within the prism layers. 1 indicates the cell is in the first layer of the prism layers.

All the boundary faces, from which the prism layers grow, obtain the number of total prism layer.

注

For imported meshes, no prism cells are detected. Therefore, no prism layer field functions are populated. Similar to the imported meshes, no prism cells are detected from meshes generated by the Turbomachinery Mesher. In prism cells generated by Directed Mesh, Tetrahedral Mesher, Advancing Layer Mesher, the quality of the prism layer detection may be decreased.


Function Name:	`PrismCellThickness`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Space models

Prism Layer Level

Outputs the prism layer indicator for a cell using the following numbers. Also works with imported volume meshes.

The values of this function correspond to the marked layer number starting from 0, for vertices and cells, respectively. When plotting this field function, due to the two sets of values in vertices and cells, the final result depends on the Contour Style.

All the non-prism cells are marked as -1.

A diagram indicating the enumeration is shown below:


Function Name:	`PartitionId`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Overset Mesh

Prism Layer Shrinkage Status

Depicts the cells in the volume mesh that the prism layer detection algorithm identifies as prism layer cells. Also works with imported volume meshes.

0 – Not a prim layer cell
> 0 – Number of the prism layer


Function Name:	`Prism Layer Shrinkage Status`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Overset mesh interfaces

Production Rate of [electrochemical species]

Displays the total amount of the [electrochemical species] (kmol) that is produced per unit volume by the bulk ion chemical reactions model.


Function Name:	`BulkIonProductionRate[electrochemical species]`
Dimensions:	[Quantity/Volume-Time]
Default units:	kmol/m^3-s
Type:	Scalar
Activated by:	Bulk Ion Chemical Reactions

Progress Variable

The progress variable,

c

in Eqn. (3535).


Function Name:	`ProgressVariable`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Flamelet Generated Manifold model, NOx Relaxation Approach (NORA) model, Turbulent Flame Speed Closure model

Progress Variable Variance

The progress variable variance is

c_{var}

in Eqn. (3331).


Function Name:	`ProgressVariableVariance`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Coherent Flame model, Turbulent Flame Speed Closure model

pro-STAR Face Id

When a face on an imported STAR-CD mesh has been assigned a boundary, this field function returns the index of the original pro-STAR boundary. In pro-STAR, this number would be plotted in response to the NUMB,BOUND,ON command.


Function Name:	`ProstarCellIndex`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Volume mesh models

pro-STAR Cell Id

This field function contains the original pro-STAR cell number for the imported STAR-CD mesh. In pro-STAR, this number would be plotted in response to the NUMB,CELL,ON command.


Function Name:	`ProstarCellIndex`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Volume mesh models

pro-STAR Cell Type

This field function contains the pro-STAR cell table index number for the imported STAR-CD mesh. In pro-STAR, this number would be plotted in response to the NUMB,TYPE,ON command.


Function Name:	`ProstarCellType`
Dimensions:	[Dimensionless]
Default units:	N/A
Type:	Scalar
Activated by:	Volume mesh models

PSTOXmode Combustion Heat Release Rate

Heat release rate due to post-flame oxidation.


Function Name:	`PSTOXmode Combustion Heat Release Rate`
Dimensions:	[Energy/Volume-Time]
Default units:	J/m³-s
Type:	Scalar
Activated by:	ECFM-3Z model, ECFM-CLEH model
